3D Elevation Views for HOA and City Review
Quick answer: A 3D elevation view for HOA and city review shows each facade straight on with materials, colors and context, built from the drawings and labeled as illustrative.
What a 3D elevation view is
An elevation is a straight-on view of one side of a building, with no perspective distortion. A 3D elevation adds materials, color, shadows and context, so a committee can read the facade the way it would look on a clear day, while keeping the proportions that reviewers are used to checking. Committees and planners like elevations because heights, window sizes and roof lines can be compared with the rules. This guide belongs to using a 3D rendering for permits, HOA and bank approval.
Why reviewers prefer elevations
Perspective images are persuasive, but they change size with distance and lens, and reviewers know it. An elevation is closer to a measurement. It shows how tall the roof is against the fence, how the windows line up and how the materials are divided. For a committee that must decide whether a design meets guidelines on height, massing or window rhythm, the elevation answers the question directly, without argument about camera angle.
Which sides to show
- Front, facing the street, is almost always required.
- Side elevations when the project is close to a neighbor or visible from a corner.
- Rear elevation when it faces a shared space, a golf course, water or an alley.
- Every side that changes, if it is an addition or remodel.
Existing and proposed side by side
For a remodel or addition, the most helpful sheet shows the existing elevation above and the proposed one below, at the same scale and aligned. The reviewer sees at a glance what changes and what stays. Mark the new areas with a light outline or a note. Do not exaggerate the contrast or hide existing features that remain. Honest comparison is what makes a committee trust the rest of the package.
Materials and colors on the elevation
Label materials directly on the image or in a legend: siding type, roof material, trim, window frame color, garage door and paint colors with their names or numbers. Many guidelines list approved palettes, and the elevation is where the committee checks them. Use real product references, not approximate colors. If a sample is required by the association, keep the same reference on the image so that what is approved is what is bought.
Scale, height and dimensions
An elevation should be built from the drawings, so the heights match. Add a scale bar or key dimensions such as ridge height, plate height and floor levels when the guidelines set limits. Remember that the image is an illustration and that the drawings control. Where a height limit is close, show the measurement on the drawing and let the image support it. Never round a dimension to make a design look compliant.
Grade, fences and landscaping
Elevations show the ground line, and it matters. If the lot slopes, the height may be measured from a specific point. Show existing and finished grade, retaining walls, fences and any planned planting that affects how the facade looks. Trees drawn at full maturity can mislead, so use sizes that are realistic for the time of installation, and say so in a note. Landscaping that screens a wall must be a commitment, not decoration.
Lighting and shadow
A neutral, even light is usually best for an elevation, with soft shadows that reveal depth without hiding details. Dramatic sunsets and strong contrast do not help a committee. Depth cues, such as shadows under eaves and around window recesses, help reviewers understand projections and overhangs. Keep the light consistent between existing and proposed views, so that differences come from the design and not from the lighting.
Windows, doors and rhythm
Committees often comment on window patterns, door styles and symmetry. Show muntins, trim widths and glass reflections in a restrained way, so the reviewer can identify the style. If the association requires a particular window type, name it in the legend. Align openings across floors when the design does that on purpose, and explain when it does not. Consistent detail is a sign that the design has been thought through.
Elevations for commercial and mixed use
For commercial buildings, planners look at street frontage, signage, transparency of ground floor windows, rooflines and materials. An elevation with the sign locations, awnings and lighting helps them review design standards. Show the relationship to neighboring buildings on the same block when the code requires compatibility. Include mechanical screening and trash enclosures, which are often overlooked and can cause comments late in the process.
Elevations for new construction in a subdivision
In a new subdivision, the design review committee often keeps a set of approved models, elevations and color packages. An elevation lets the committee compare your house with the neighbors and check that the same facade is not repeated too close. Show the chosen elevation option, the garage orientation and the roof material. If the builder offers several, label the one that applies to your lot so that approvals do not get mixed up.
Accuracy over beauty
It is tempting to make an elevation look as attractive as possible, but committees can spot flattery. A neutral, accurate image builds trust and prevents disputes at inspection, when the finished house is compared with what was approved. If a detail is not decided, say so in a note, or show the most likely option and label it. A modest, exact drawing is more useful than a dramatic one that cannot be built.
File formats and sheet layout
Prepare the elevations on sheets that match the association or city format, with a title, address, scale, date and revision number. Save a PDF for the portal, and keep a high resolution image for printing at meetings. Name the files with the address and the sheet name. When you revise, increase the revision number and keep the old version, so you can explain what changed between rounds.
After approval
After approval, keep the elevation with the approval letter. Builders and inspectors use it to check color, materials and details. If you want to change a color or a window later, review the approval conditions and ask before you build. Many associations require a new request for changes, and an updated elevation makes that request fast to prepare and easy to review.
Roofs, chimneys and mechanical items
Roof shape and pitch, chimneys, vents, solar panels, satellite dishes and mechanical equipment are frequent causes of comments. Show them, even when they are small. If a rule bans visible equipment from the street, show where it goes and how it is screened. Hiding them from the image and revealing them later is a fast way to lose trust, and it can create a violation after construction.
Pairing elevations with a perspective
The best packages use both. The elevation gives the measurable facts, and one or two perspective views show how the building feels from the street. Keep the same materials, colors and details on every image. If they differ, the committee will ask which is correct. A consistent set makes the review simple, and it reduces the risk of a conditional approval based on differences between views.
What to send the studio
- Final or near final elevations and floor plans.
- A site plan with grade information.
- The material list with brands, colors and finish names.
- Photos of the existing house and neighbors.
- The guideline pages that set height, color or style rules.
Cost and timing
An elevation set is usually faster than a full perspective package, but it depends on how many sides are needed and how many revisions the committee requests. See how long a 3D rendering takes. Rendimension offers an express option, subject to the queue, when a meeting date is close.
Questions to ask the studio
- Will you build from my drawings and match the dimensions?
- Can you deliver existing and proposed elevations at the same scale?
- Can you label materials and colors on the image?
- How many revision rounds are included?
- Can you provide the files in the format the portal accepts?
A checklist before you submit
- Every visible side is shown.
- Materials and colors are labeled and match the samples.
- Heights match the drawings.
- Grade, fences and equipment are visible.
- Landscaping is realistic for installation.
- The image is labeled as illustrative and the drawings control.
Revision rounds and how to keep them small
For using elevation views for HOA and city review, the large decisions belong in the first preview: the massing, the materials, the colors and the camera. After that, send changes as one consolidated list. A reviewer or lender will judge the image against your written documents, so any correction should keep the two consistent. See how revision rounds affect timelines.
Timing
Approval dates are usually set by someone else: a meeting calendar, a filing deadline, a closing date. Count backward from that date, leave room for one revision round and answer the studio quickly. See how long a 3D rendering takes. Rendimension offers an express option, subject to the queue, when a date is fixed.
Common mistakes
- Drawing them from the concept instead of the final plans.
- Using a different scale for existing and proposed views.
- Leaving out materials and color names.
- Hiding equipment or grade changes.
- Showing mature trees that do not exist yet.
- Making the perspective differ from the elevation.
A worked example
An owner adds a second story to a house in an HOA. The studio prepares front and side elevations with existing above and proposed below, at the same scale, with materials and colors named and the roof ridge labeled against the limit. The committee checks the height, the palette and the window pattern in one meeting, asks for a darker trim color and approves after the label is updated.
Where to go next
Ask the reviewing body for its checklist, then send the checklist, your drawings or sketch and your references to the studio. For the general overview, see using a 3D rendering for permits, HOA and bank approval, and for the pitfalls to avoid, see common mistakes using a rendering for approvals.
Frequently asked questions
What is a 3D elevation view?
A straight-on view of one side of a building with materials, color and shadow, without perspective distortion.
Why do HOAs like elevations?
Heights, windows and materials can be compared with the guidelines.
Which sides should I show?
The street side and any side that changes or is visible to neighbors.
Should existing and proposed be shown together?
Yes, at the same scale and aligned.
Do I need to label materials?
Yes, with real product names and colors.
Does it replace drawings?
No. The drawings control.
Can I add a perspective?
Yes, with the same materials and details.
Is there a faster option?
Rendimension offers an express option, subject to the queue.
